Compressor Processes Liquids | Works With Any Lift System | No Pneumatic Valves or Vessels | Automated Capacity Control | SkyView Reporting | Set & Forget PLC Control
Standard Features
- Purpose design for low volume casing gas applications
- No operator setup or adjustment is required
- Eliminates issues common with conventional casing gas compressors
- No liquid handling system (compressor can pump liquid or gas)
- NO separator, level shutoff or switch
- NO liquid pump
- No liquid handling system (compressor can pump liquid or gas)
- Ultra-reliable gear pump and electric motor power supply
- Minimal moving parts, minimal maintenance
- Easy and inexpensive to move
- Live SkyView reporting system instantly notifies of system warnings and shutdowns
- No external leak points for oil or gas seals
- Automatic restart if grid power is lost
- Optimize separately from the lift system
- Compressor will adjust cycle rate to match flow
- Up to 100% turn down
- Start and walk away oil warm-up system
Options/Configurations
- Multiple Rod Sizes Available
- Sweet or Sour Service
- Skid or Gas Trailer Available – towable by a ¾ ton truck
- Electric or Gas Drive Engine Power Packs
- Hydraulic Heat Trace
- Sour Corrosion PSV
- Sour Corrosion XXS Piping
- Inlet Particle Filter
| Motor | 50hp |
| Operating Pressure Range | 0 - 1500psi |
| Flow Range | 35 - 500mscfd |
| HCG50 Compressor Weight | 2600 lbs (incl. concrete slab) |
| Power Pack Weight (Electric) | 2587 lbs |
| Power Pack Weight (Gas) | 2861 lbs |
| Compressor Dimensions | Length: 96" Width: 24" Height: 48.5" |
| Power Pack Dimensions (Electric) | Length: 96" Width: 53" Height: 66" |
| Power Pack Dimensions (Gas) | Length: 108" Width: 70 Height: 92" |
| Casing Gas Compression (Sweet & Sour Service) |
| Pigging |
| Poor Boy Gas Lift |
| Multi-phase pump |
 |
HCG Brochure
HCG Application Data SheetPerformance
CHC1050 with HC1022 Compressor
| DISCHARGE PRESSURE Max ΔP: 225 psi / 1550 kPa | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SUCTION |
PSI kPa |
75 520 |
100 700 |
125 860 |
150 1035 |
175 1205 |
200 1380 |
225 1550 |
250 1725 |
275 1900 |
300 2070 |
325 2240 |
350 2420 |
| 5 35 |
100 2.8 |
95 2.7 |
91 2.6 |
87 2.5 |
83 2.4 |
79 2.3 |
75 2.1 |
||||||
| 10 70 |
130 3.7 |
125 3.6 |
121 3.5 |
117 3.3 |
112 3.2 |
108 3.1 |
104 3.0 |
||||||
| 15 105 |
160 4.6 |
156 4.5 |
151 4.3 |
147 4.2 |
147 4.2 |
138 3.9 |
134 3.8 |
||||||
| 20 140 |
191 5.5 |
186 5.3 |
181 5.2 |
177 5.1 |
172 4.9 |
168 4.8 |
164 4.7 |
||||||
| 30 210 |
252 7.2 |
247 7.1 |
242 6.9 |
237 6.8 |
233 6.6 |
228 6.5 |
223 6.4 |
219 6.3 |
|||||
| 40 275 |
314 9.0 |
308 8.8 |
303 8.7 |
298 8.5 |
293 8.4 |
288 8.2 |
284 8.1 |
279 8.0 |
|||||
| 50 345 |
376 10.7 |
370 10.6 |
364 10.4 |
359 10.3 |
354 10.1 |
349 10.0 |
344 9.8 |
339 9.7 |
334 9.5 |
||||
| 75 520 |
525 15.0 |
519 14.8 |
513 14.6 |
507 14.5 |
501 14.3 |
496 14.1 |
491 14.0 |
485 13.9 |
480 13.7 |
||||
| 100 700 |
674 19.3 |
667 19.1 |
661 18.9 |
655 18.7 |
649 18.5 |
643 18.4 |
637 18.2 |
632 18.1 |
626 17.9 |
||||
| 125 860 |
823 23.5 |
816 23.3 |
809 23.1 |
802 22.9 |
769 22.0 |
790 22.6 |
748 21.4 |
778 22.2 |
773 22.1 |
||||
| 150 1035 |
972 27.8 |
964 27.6 |
957 27.3 |
950 27.2 |
944 27.0 |
937 26.8 |
931 26.6 |
925 26.4 |
|||||
| 175 1205 |
1120 32.0 |
1113 31.8 |
1105 31.6 |
1098 31.4 |
1091 31.2 |
1084 31.0 |
1078 30.8 |
||||||
| 200 1380 |
1269 36.3 |
1261 36.0 |
1254 35.8 |
1246 35.6 |
1239 35.4 |
1232 35.2 |
|||||||
| Projected Performance based on 2500 ft, gas density .665, temp 68ºF – Flow Rates in mscfd e3m3/day | |||||||||||||
CHC1050 with HC1028 Compressor
| DISCHARGE PRESSURE Max ΔP: 380 psi / 2620 kPa | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SUCTION |
PSI kPa |
250 1725 |
275 1900 |
300 2070 |
325 2240 |
350 2420 |
375 2585 |
400 2760 |
425 2930 |
450 3100 |
475 3275 |
500 3450 |
525 3620 |
|
| 5 35 |
41 1.2 |
39 1.1 |
36 1.0 |
34 1.0 |
32 0.9 |
30 0.9 |
||||||||
| 10 70 |
58 1.7 |
56 1.6 |
53 1.5 |
52 1.5 |
49 1.4 |
47 1.3 |
||||||||
| 15 105 |
75 2.2 |
73 2.1 |
71 2.0 |
68 2.0 |
66 1.9 |
64 1.8 |
||||||||
| 20 140 |
93 2.7 |
90 2.6 |
88 2.5 |
86 2.4 |
83 2.4 |
81 2.3 |
78 2.2 |
|||||||
| 30 210 |
128 3.7 |
125 3.6 |
123 3.5 |
120 3.4 |
118 3.4 |
115 3.3 |
113 3.2 |
|||||||
| 40 275 |
163 4.7 |
161 4.6 |
158 4.5 |
155 4.4 |
157 4.5 |
150 4.3 |
148 4.2 |
|||||||
| 50 345 |
199 5.7 |
196 5.6 |
193 5.5 |
191 5.4 |
188 5.4 |
185 5.3 |
183 5.2 |
180 5.1 |
||||||
| 75 520 |
288 8.2 |
285 8.1 |
282 8.0 |
279 8.0 |
276 7.9 |
273 7.8 |
271 7.7 |
268 7.7 |
265 7.6 |
|||||
| 100 700 |
378 10.8 |
374 10.7 |
371 10.6 |
368 10.5 |
365 10.4 |
362 10.3 |
359 10.3 |
356 10.2 |
353 10.1 |
350 10.0 |
||||
| 125 860 |
468 13.4 |
464 13.3 |
460 13.2 |
458 13.1 |
454 13.0 |
451 12.9 |
448 12.8 |
445 12.7 |
442 12.6 |
439 12.5 |
436 12.5 |
|||
| 150 1035 |
558 16.0 |
555 15.8 |
551 15.7 |
547 15.6 |
544 15.5 |
541 15.5 |
538 15.4 |
534 15.3 |
531 15.2 |
528 15.1 |
524 15.0 |
521 14.9 |
||
| 175 1205 |
649 18.5 |
645 18.4 |
641 18.3 |
638 18.2 |
634 18.1 |
630 18.0 |
627 17.9 |
624 17.8 |
620 17.7 |
617 17.6 |
613 17.5 |
610 17.4 |
||
| 200 1380 |
740 21.2 |
736 21.0 |
732 20.9 |
728 20.8 |
724 20.7 |
721 20.6 |
717 20.5 |
713 20.4 |
710 20.3 |
706 20.2 |
703 20.1 |
699 20.0 |
||
| Projected Performance based on 2500 ft, gas density .665, temp 68ºF – Flow Rates in mscfd e3m3/day | ||||||||||||||
